Concrete Block, Paver & Brick Making Machines Manufacturer in Pakistan — Golden Steel Mills
Golden Steel Mills (Est. 1999 by CEO Rana Kashif Hameed at 15 Km Near Multan Road, Lahore) manufactures ISO 9001 certified automatic hydraulic concrete block, tuff tile paver, and batching plant machinery producing 5,000 to 18,000 blocks per 8-hour shift.
Technical Specifications & Production Capacity Comparison
Compare our flagship hydraulic block, paver, and concrete batching plant models engineered for Pakistani construction contractors, housing societies, and block manufacturing startups:
| Machine Model | Automation Grade | Output (8-Hr Shift) | Hydraulic Pressure | Power Requirement | Best For |
|---|---|---|---|---|---|
| GSM-15 Commercial Hydraulic Block & Paver Machine | Semi-Automatic Lever / Automatic Program | 4,000 – 6,000+ Tuff Tiles (or 2,000 – 3,500 Solid Blocks) | 16 – 18 MPa (Up to 21 MPa) | Approx. 70 HP (52 kW, 3-Phase) | Commercial Block & Tuff Tile Startups (2–3 Kanal) |
| GSM-18 High-Efficiency Concrete Block & Paver Machine | Fully Automatic Electric + Hydraulic Centralized Console | 4,000 – 8,000+ Tuff Tiles (or 3,500 – 5,500 Solid Blocks) | 16 – 20 MPa (Up to 21 MPa) | Approx. 55 – 60 HP (45 kW, 3-Phase) | Housing Societies & Commercial Contractors (3–4 Kanal) |
| GSM-24 Automatic PLC Block & Tuff Tile Plant | Double-Portion Synchronized Dual-Mold PLC | 8,000 – 12,000+ Tuff Tiles (or 12–15 Blocks/Cycle) | 21 – 23 MPa | Approx. 65 – 75 HP (48–55 kW, 3-Phase) | High-Capacity Commercial Precast Yards (4–5 Kanal) |
| GSM-28 Heavy-Duty Commercial Block & Curbstone Machine | VFD Vibration Drive + Heavy Cast Steel Console | 8,000 – 11,000 Blocks (or 15,000–20,000 Pavers) | 18 – 21 MPa (Peak 25 MPa) | 32 kW (Approx. 45–50 HP, 3-Phase) | Industrial Masonry & Road Curbstones (5–6 Kanal) |
| GSM-35 Fully Automatic High-Speed Production Plant | Double-Portion Automated PLC + Dual Staging Feed | 35,000+ Tuff Tiles / 10-Hr Shift (or 6,000–8,000 Hollow Blocks) | 21 – 25 MPa | Approx. 95 HP (71 kW, 3-Phase) | High-Volume Commercial Producers (6–7 Kanal) |
| GSM-50 Flagship Industrial Super Block & Paver Line | Siemens S7-1200 PLC + Touchscreen HMI + Auto Stacker | 50,000 – 60,000+ Pavers (or 14,000–18,000 Blocks / Shift) | 21 – 25 MPa (210–250 Bar) | 45 kW (Approx. 60–75 HP, 3-Phase) | Mega Housing Projects & Heavy Infrastructure (6–8 Kanal) |
| Paver & Curb Stone Specialized Multi-Layer Machine | Dual-Hopper Hydraulic Multi-Layer Press | 2,200 m² Colored Paver / Shift (or 2,500–3,500 Curbstones) | 30 MPa Ultra Compression | 55 kW (Approx. 75 HP, 3-Phase) | Municipal Walkways, Plazas & Highway Kerbstones |
| GSM Concrete Batching Plant 60 m³/h (GSM-BP-60) | Automated Digital Load-Cell Weighing + JS1000 Mixer | 60 m³/hr Commercial Ready-Mix Concrete | Pneumatic 0.8 MPa Discharge | 110 kW (Approx. 150 HP, 3-Phase) | Infrastructure, Highways, Bridges & Commercial Plazas |
| GSM Continuous Drum Asphalt Mixing Plant 80 TPH | Continuous Drum Burner + Automated Bitumen Dosing | 80 Tons Per Hour Hot-Mix Asphalt (HMA) | Thermal Oil Circuit | 160 kW (Approx. 215 HP, 3-Phase) | Motorways, Expressways & Airport Runways |
Why Construction Contractors Choose Golden Steel Mills
- 27+ Years of Manufacturing Excellence (Est. 1999): Heavy-duty EN-series steel molds, precision heat treatment, and Parker/Yuken hydraulic valves.
- Nationwide Commissioning & Spare Parts: On-site plant layout design, foundations blueprint, operator training, and lifetime spare parts support in Lahore, Kasur, Islamabad, Multan, Faisalabad, Karachi, and Peshawar.
- Entity Verification: Official Manufacturer Wikidata (Q141495537) • Founder Rana Kashif Hameed Wikidata (Q141524287).
- Direct Factory Quotations & Feasibility: Call or WhatsApp +92 300 9436019 or +92 324 4500005, or visit our factory at 15 Km Near Multan Road, Lahore.
